Thread: Whats this?? Body fixing part

  1. 27th August 2012, 07:48 PM #1
    stuee's Avatar
    stuee
    stuee is offline Wizard Subscriber
    Join Date
    Jan 1970
    Location
    Perth
    Posts
    1,180
    Total Downloaded
    0

    Whats this?? Body fixing part

    I have no idea what the correct name of the below is but I need more to finish off my 101. Anyone able to help? Its some sort of captive nut/thread/thingamabob fixed to the body by 3.2mm countersunk rivets.

    This one went through a galv bath with some other items hence the rough edges and the 3.2mm holes filled in (coloured in black with a sharpie so it looks normal).

    I have the 3.2mm countersunk rivets I need to fix them to the various body parts but missing about 4-5 of the things so far.




    Reply With Quote Reply With Quote
  2. 27th August 2012, 08:37 PM #2
    bee utey's Avatar
    bee utey
    bee utey is offline AT REST
    Join Date
    Apr 2009
    Location
    Crafers West South Australia
    Posts
    11,732
    Total Downloaded
    0
    Turnlock fasteners?

    TURNLOCK FASTENERS

    Reply With Quote Reply With Quote
  3. 27th August 2012, 08:43 PM #3
    101RRS's Avatar
    101RRS
    101RRS is offline LordRover Supporter
    Join Date
    Jan 1970
    Location
    Canberra
    Posts
    18,616
    Total Downloaded
    0
    I have bought them from the 101 club when I was a member - were listed near the end of the parts list.

    Garry
    REMLR 243

    2007 Range Rover Sport TDV6
    1977 FC 101
    1976 Jaguar XJ12C
    1973 Haflinger AP700
    1971 Jaguar V12 E-Type Series 3 Roadster
    1957 Series 1 88"
    1957 Series 1 88" Station Wagon
    Reply With Quote Reply With Quote
  4. 27th August 2012, 09:14 PM #4
    stuee's Avatar
    stuee
    stuee is offline Wizard Subscriber
    Join Date
    Jan 1970
    Location
    Perth
    Posts
    1,180
    Total Downloaded
    0
    Camlocs Garry? These appear to be the same as what bee utey posted up. I have looked at these before but it seems as though they had more of a socket when I googled them rather than the plate looking item I have. Ill look further on the 101 club forum to see if there are any pics.
    Reply With Quote Reply With Quote
  5. 28th August 2012, 01:03 PM #5
    strangy
    strangy is offline ChatterBox
    Join Date
    May 2007
    Location
    Australia
    Posts
    2,827
    Total Downloaded
    0
    AKA Zuss fasteners. Very common on Aircraft cowlings.

    Cheers
    Reply With Quote Reply With Quote
  6. 28th August 2012, 08:56 PM #6
    Davo
    Davo is offline ChatterBox Silver Subscriber
    Join Date
    May 2007
    Location
    WA
    Posts
    2,595
    Total Downloaded
    0
    The parts book calls them camlocs and the part number is 399220 - which didn't come up on any Google searches for me!
    At any given point in time, somewhere in the world someone is working on a Land-Rover.
    Reply With Quote Reply With Quote
  7. 29th August 2012, 04:52 AM #7
    stuee's Avatar
    stuee
    stuee is offline Wizard Subscriber
    Join Date
    Jan 1970
    Location
    Perth
    Posts
    1,180
    Total Downloaded
    0
    They are indeed in the parts book. I found a decent post that highlights all the camlocs used on a 101 on the club forum:
    101 club • Login

    They are on page 32-72/32-73 and are item number 11 "Camloc Receptacal", part number as per Davo's post.

    All of the camloc parts are available from the 101 club new. I'm thinking of just ordering all required items so I have them for the future rather than search through the various parts bags I have as I haven't seen many camlocs or receptacals through them to date.

    Thanks All!
    Reply With Quote Reply With Quote
