Thread: Dyneema rope + fairlead rollers - setup?

  1. 20th July 2012, 01:02 PM #1
    Daner
    Daner is offline Fossicker
    Join Date
    Feb 2012
    Location
    Melbourne
    Posts
    13
    Total Downloaded
    0

    Dyneema rope + fairlead rollers - setup?

    http://i514.photobucket.com/albums/t...o/IMG_2482.jpg

    Just performed a winch upgrade and installed a Tigerz11 1200lb winch into my ARB bull bar. The winch came with Dyneema rope and everyone i spoke to said "you must run a hawse plate" The thing is I have a bull bar designed to use fairlead rollers. Using purely a hawse plate would enable the rope to come into contact with the protruding steel designed to take the fairlead rollers – under pressure, this could be a nasty situation J

    So, after some deliberations, a couple of beers, taking into consideration all this talk of rope getting caught up in the corner of the rollers etc, I decided to do some preliminary testing of the rope running through the rollers at all sorts of angles. I just can’t see how the rope would get stuck or damaged as long as the rollers are in good shape.

    So after purchasing a new set of rollers to ensure no rough parts etc, I installed the winch and failread setup.

    Can anyone tell me conclusively if I’m going to have issues? Anyone done similar – feed back etc appreciated.

    Thanks,



    R,
    Reply With Quote Reply With Quote
  2. 20th July 2012, 01:07 PM #2
    MR LR
    MR LR is offline ChatterBox
    Join Date
    Apr 2009
    Location
    South Sydney
    Posts
    2,499
    Total Downloaded
    0
    On 4wd tv, they installed plastic rollers as a fella had a bull bar designed for a roller fairlead, they were black, i fail to see how the rope could get caught, but anyway.
    Reply With Quote Reply With Quote
  3. 20th July 2012, 01:14 PM #3
    THE BOOGER's Avatar
    THE BOOGER
    THE BOOGER is offline AT REST
    Join Date
    Oct 2007
    Location
    wetherill park
    Posts
    2,600
    Total Downloaded
    0
    I run a hawse plate but have looked at rollers before I got the dyneema if the rollers are set up right getting the rope caught would be a rare thing only likely to happen on an extreme angle pull, but if it did happen the the rope would be US maybe even break at a bad point of a winch op. I do think in on the whole the risk is overstated but you never know
    Reply With Quote Reply With Quote
  4. 20th July 2012, 04:24 PM #4
    TimNZ's Avatar
    TimNZ
    TimNZ is offline Wizard
    Join Date
    Mar 2008
    Location
    Perth, WA
    Posts
    1,947
    Total Downloaded
    0
    I just fitted the nylon rollers from ARB.....

    Cheers,
    Reply With Quote Reply With Quote
  5. 20th July 2012, 08:37 PM #5
    RVR110's Avatar
    RVR110
    RVR110 is offline Master Subscriber
    Join Date
    Feb 2010
    Location
    Sutherland Shire, Sydney
    Posts
    844
    Total Downloaded
    0
    Rope Rollers for Synthetic Winch Rope

    While you're at it, you can tidy things up with one of these.

    I usually buy Daystar stuff from Expedition Exchange, but at the moment they don't seem to have the polyurethane rollers listed on their website.

    [ame="http://www.youtube.com/watch?v=ReHqZe3X8as"]Daystar Polyurethane Fairlead Rollers[/ame]
    Reply With Quote Reply With Quote
