  1. 17th March 2015, 08:48 PM #11
    scarry's Avatar
    scarry
    scarry is offline Swaggie
    Join Date
    Apr 2008
    Location
    Brisbane,some of the time.
    Posts
    13,910
    Total Downloaded
    0
    I would tech screw the angle to the posts,using fine threaded screws.

    Then use pop rivets on the slats.You could also use tech screws but may not look very good as you will be able to see the end of the screws poking through.

    The difficult part of the job will be getting all the measurements correct so it all looks good when finished.

    Good luck.
    Reply With Quote Reply With Quote
  2. 17th March 2015, 09:45 PM #12
    350RRC's Avatar
    350RRC
    350RRC is offline ForumSage Silver Subscriber
    Join Date
    Mar 2008
    Location
    Bellarine Peninsula, Brackistan
    Posts
    5,507
    Total Downloaded
    0
    Self tapping metal screws will drill and hold in 4mm no probs. Hex head gal coarse thread.

    The way they drill will make you wonder about why drill bits were ever invented for metal.

    You will need a good variable speed drill with grunt, battery or 240.

    DL
    Reply With Quote Reply With Quote
  3. 17th March 2015, 11:14 PM #13
    d2dave's Avatar
    d2dave
    d2dave is offline ForumSage Subscriber
    Join Date
    May 2009
    Location
    Tatura, Vic
    Posts
    6,342
    Total Downloaded
    0
    Why the aluminum angle? If it was me I would just Tek screw the horizontals to the posts.
    Dave.

    I was asked " Is it ignorance or apathy?" I replied "I don't know and I don't care."


    1983 RR gone (wish I kept it)
    1996 TDI ES.
    2003 TD5 HSE
    1987 Isuzu County
    Reply With Quote Reply With Quote
  4. 17th March 2015, 11:21 PM #14
    33chinacars
    33chinacars is offline Wizard Subscriber
    Join Date
    Dec 2009
    Location
    Tyrendarra Vic (South West Vic )
    Posts
    1,729
    Total Downloaded
    0
    I'd Tek screw direct to post's
    Reply With Quote Reply With Quote
  5. 18th March 2015, 05:29 AM #15
    WhiteD3
    WhiteD3 is offline TopicToaster
    Join Date
    Feb 2007
    Location
    Brisbane
    Posts
    4,497
    Total Downloaded
    0
    Quote Originally Posted by d2dave View Post
    Why the aluminum angle? If it was me I would just Tek screw the horizontals to the posts.
    Using the angle allows me to keep all the fixings on the inside of the carport. On the lawn side all you'll see is smooth, power coated slat.
    Reply With Quote Reply With Quote
  6. 18th March 2015, 05:30 AM #16
    WhiteD3
    WhiteD3 is offline TopicToaster
    Join Date
    Feb 2007
    Location
    Brisbane
    Posts
    4,497
    Total Downloaded
    0
    Quote Originally Posted by pop058 View Post
    Agree with Bee Uty. I (shed builder) use 14g FINE THREAD self drillers (Tek screws) to attached framing (C purlins, tophat, etc.) to RHS posts for carports. These are all engineered for use in cyclonic areas.
    What about rustproofing these self taped holes. Required or not?
    Reply With Quote Reply With Quote
  7. 18th March 2015, 06:34 AM #17
    JDNSW's Avatar
    JDNSW
    JDNSW is offline RoverLord Silver Subscriber
    Join Date
    Jan 1970
    Location
    Central West NSW
    Posts
    29,538
    Total Downloaded
    0
    Quote Originally Posted by WhiteD3 View Post
    What about rustproofing these self taped holes. Required or not?
    The screws are galvanised (assuming you use the right ones!) and the zinc layer provides galvanic protection for the holes. If in a severe corrosion area (e.g. beachfront) a spot of penetrating sealant may be indicated.

    John
    John

    JDNSW
    1986 110 County 3.9 diesel
    1970 2a 109 2.25 petrol
    Reply With Quote Reply With Quote
  8. 4th April 2015, 01:58 PM #18
    WhiteD3
    WhiteD3 is offline TopicToaster
    Join Date
    Feb 2007
    Location
    Brisbane
    Posts
    4,497
    Total Downloaded
    0
    All done. Thanks for the tips Gents.





    Reply With Quote Reply With Quote
  9. 5th April 2015, 11:15 AM #19
    ramblingboy42's Avatar
    ramblingboy42
    ramblingboy42 is offline Swaggie Silver Subscriber
    Join Date
    Jun 2008
    Location
    The new Gold Coast, after ocean rises,Queensland
    Posts
    13,204
    Total Downloaded
    0
    looks great, makes you feel good when you do a pro job don't it?
    Reply With Quote Reply With Quote
  10. 6th April 2015, 09:40 AM #20
    UncleHo's Avatar
    UncleHo
    UncleHo is offline AT REST
    Join Date
    Oct 2003
    Location
    Godwin Beach Qld
    Posts
    8,688
    Total Downloaded
    0
    That will slow the rain and hail
    Reply With Quote Reply With Quote
