Thread: Oil Catch Can for D4

Originally Posted by dalil

Hi, I have installed Flash lube catch can in my 2013 D4, it actually works. On 600km trip the draining hose was full of oil so CCV doesn't work. I don't know how long i will keep my car, but if i decide to hold on few more years

...

The Flashlube product is made by MANN+HUMMEL for Don Kyatt (Flashlube).

Dalil,
How did you get to the breather pipe? I was led to believe they're at the rear of the engine, and therefore inaccessible with the body on.
Thanx.

Originally Posted by dalil

Hi, I have installed Flash lube catch can in my 2013 D4, it actually works. On 600km trip the draining hose was full of oil so CCV doesn't work. I don't know how long i will keep my car, but if i decide to hold on few more years





I too would be interested how you were able to fit the oil catch can

Factory separation-

Sorry for late reply, i just got back from Vic. High country.
I got few photos, it may help.
I disconnect hose at the crankcase separator - Just behind oil filter ( bypass pipe that is in back of the engine) and connect PVC hose that go to Catch can "IN". Return "Out"go down to the other side of the bypassed pipe just before primary turbo. You can access by removing aluminium cover in left hand wheel arch.
Dali

Sketch how I modify factory breather.
Dali

Do you drain the oil manually?

Outstanding. Thanks dalil
