Thread: Compressor change problem

  1. 7th May 2018, 04:02 PM #1
    SeanC's Avatar
    SeanC
    SeanC is offline Master Subscriber
    Join Date
    Jul 2016
    Location
    Blackstone
    Posts
    469
    Total Downloaded
    0

    Compressor change problem

    I changed the compressor in my 08 D3 today. It was a AMK for AMK swap. I also changed the reservior valve block.

    The new compressor raised the vehicle from bump stops to off-road with no problems but it is not cutting out. It runs whenever the vehicle is running.

    Checked for for leaks at all air hoses I had disconnected and re-connected. None found. Checked all electrical connections. The relay was replaced with the one supplied with the compressor.

    No faults. Any ideas?

    Next step will be to put the old compressor back in to see if the problem remains.


    Thanks.
    Sean.
    Reply With Quote Reply With Quote
  2. 7th May 2018, 04:14 PM #2
    Geedublya
    Geedublya is offline Wizard Silver Subscriber
    Join Date
    Dec 2009
    Location
    Ranelagh, Tasmania
    Posts
    1,543
    Total Downloaded
    0
    Replace the new relay with the original first. It may be faulty.
    Fuji white RRS L494 AB Gone
    2023 Ford Ranga
    Reply With Quote Reply With Quote
  3. 7th May 2018, 04:52 PM #3
    SeanC's Avatar
    SeanC
    SeanC is offline Master Subscriber
    Join Date
    Jul 2016
    Location
    Blackstone
    Posts
    469
    Total Downloaded
    0
    Tried that but no luck.
    Reply With Quote Reply With Quote
  4. 7th May 2018, 04:55 PM #4
    Tombie Guest
    Try a hard reset and then continue diagnostics.
    Reply With Quote Reply With Quote
  5. 8th May 2018, 04:17 PM #5
    SeanC's Avatar
    SeanC
    SeanC is offline Master Subscriber
    Join Date
    Jul 2016
    Location
    Blackstone
    Posts
    469
    Total Downloaded
    0
    Quote Originally Posted by Tombie View Post
    Try a hard reset and then continue diagnostics.
    Got home this afternoon and it seems to be behaving perfectly. Compressor cutting out when it gets to about 1780kpa. Valves and relay working fine.

    Yesterday it it was running even when the suspension was lowering.

    The only thing I can think of was that after of starting and stopping the D3 while testing the compressor yesterday the starting battery would barely turn the motor over so I had to use the auxiliary battery.

    Got a number of faults for lost communication which normally happens when you disconnect the battery.

    So maybe the flat battery was like a hard re-set.

    Now I have to work out how the upper compressor cover fits back in.
    Reply With Quote Reply With Quote
  6. 10th May 2018, 05:01 PM #6
    SeanC's Avatar
    SeanC
    SeanC is offline Master Subscriber
    Join Date
    Jul 2016
    Location
    Blackstone
    Posts
    469
    Total Downloaded
    0
    The compressor I removed was a Land Rover branded AMK compressor and the new compressor is a Britpart.
    The only difference is the silver threaded cap on the right hand above the brass fitting on the Britpart.
    Anyone know what this is for?
    Reply With Quote Reply With Quote
  7. 10th May 2018, 06:27 PM #7
    discorevy
    discorevy is offline ChatterBox Subscriber
    Join Date
    Nov 2014
    Location
    Nirvana near Albany W.A.
    Posts
    2,480
    Total Downloaded
    0
    Threaded cap was where the air link pipe went on the old style amk compressor from memory
    Reply With Quote Reply With Quote
  8. 10th May 2018, 09:14 PM #8
    SeanC's Avatar
    SeanC
    SeanC is offline Master Subscriber
    Join Date
    Jul 2016
    Location
    Blackstone
    Posts
    469
    Total Downloaded
    0
    Quote Originally Posted by discorevy View Post
    Threaded cap was where the air link pipe went on the old style amk compressor from memory
    As long as doesn’t need to connected to anything then all is good.
    Reply With Quote Reply With Quote
