    Drilling rig air intake

    can anyone help me out with the name and purpose of thing seen in this photo coming off the air intake filter assembly at approximately 7 o'clock in this photo.



    it is like some kind of rubber dump valve I think but it would be great if someone could clarify.

    Thanks

    John
    Reply With Quote Reply With Quote
  2. 2nd March 2015, 05:18 PM #2
    p38arover's Avatar
    p38arover
    p38arover is offline Major part of the heart and soul of AULRO.com
    Administrator
    I'm here to help you!     Gold Subscriber
    Join Date
    Jan 1970
    Location
    Western Sydney
    Posts
    30,728
    Total Downloaded
    1.63 MB
    It looks like the dump valve on RRC air cleaners.
    Ron B.
    VK2OTC

    2003 L322 Range Rover Vogue 4.4 V8 Auto
    2007 Yamaha XJR1300
    Previous: 1983, 1986 RRC; 1995, 1996 P38A; 1995 Disco1; 1984 V8 County 110; Series IIA



    RIP Bucko - Riding on Forever
    Reply With Quote Reply With Quote
  3. 2nd March 2015, 05:23 PM #3
    LandyAndy's Avatar
    LandyAndy
    LandyAndy is offline RoverLord Gold Subscriber
    Join Date
    Feb 2004
    Location
    Williams West Aust
    Posts
    20,998
    Total Downloaded
    0
    The air cleaner has a cyclone action,dirt accumulates in that tube.Before starting you squeeze the gland and it releases the dirt.Its shaped like that to collapse onto itself whilst the engine is running so it is air/water resistant.Very common on most earthmoving/farming equipment.
    Andrew
    DISCOVERY IS TO BE DISOWNED
    Midlife Crisis.Im going to get stuck into mine early and ENJOY it.
    Snow White MY14 TDV6 D4
    Alotta Fagina MY14 CAT 12M Motor Grader
    2003 Stacer 525 Sea Master Sport
    I made the 1 millionth AULRO post
    Reply With Quote Reply With Quote
  4. 2nd March 2015, 07:09 PM #4
    Don 130's Avatar
    Don 130
    Don 130 is offline ChatterBox Supporter
    Join Date
    Oct 2007
    Location
    Wantabadgery, N.S.W.
    Posts
    2,744
    Total Downloaded
    0
    I've seen it described as a duck bill valve.
    Duckbill valve - Wikipedia, the free encyclopedia
    Don
    Reply With Quote Reply With Quote
  5. 2nd March 2015, 09:25 PM #5
    LandyAndy's Avatar
    LandyAndy
    LandyAndy is offline RoverLord Gold Subscriber
    Join Date
    Feb 2004
    Location
    Williams West Aust
    Posts
    20,998
    Total Downloaded
    0
    Quote Originally Posted by Don 130 View Post
    I've seen it described as a duck bill valve.
    Duckbill valve - Wikipedia, the free encyclopedia
    Don
    I was trying to think of what it was called,kept thinking ducks beak,you are correct.
