Thread: front brake pads - which side the taper?

  1. 11th August 2007, 01:17 PM #1
    dusty disco
    dusty disco is offline Fossicker Supporter
    Join Date
    Mar 2007
    Location
    Perth W Australia
    Posts
    60
    Total Downloaded
    0

    front brake pads - which side the taper?

    Hi all

    I am stumped on this one. The replacement pads have a taper in the brake lining material on the one side only ie. the pads are installed with the tapered part either on the 'leading' side or the 'trailing' edge. Neither the instructions nor my Haynes manual refere to this, and the pads that came out appear not ot have a chamfer at all.

    Should this taper be on the leading or trailing edge? Anybody know?

    Thanks

    Adrian
    Reply With Quote Reply With Quote
  2. 11th August 2007, 01:52 PM #2
    Blknight.aus's Avatar
    Blknight.aus
    Blknight.aus is offline RoverLord Vendor
    Join Date
    Aug 2006
    Location
    Melbourn(ish)
    Posts
    26,495
    Total Downloaded
    0
    the taper should be on the rearwards side, Thats how Ive always installed them.
    Dave

    "In a Landrover the other vehicle is your crumple zone."

    For spelling call Rogets, for mechanicing call me.

    Fozzy, 2.25D SIII Ex DCA Ute
    Tdi autoManual d1 (gave it to the Mupion)
    Archaeoptersix 1990 6x6 dual cab(This things staying)


    If you've benefited from one or more of my posts please remember, your taxes paid for my skill sets, I'm just trying to make sure you get your monies worth.
    If you think you're in front on the deal, pay it forwards.
    Reply With Quote Reply With Quote
  3. 11th August 2007, 02:05 PM #3
    dusty disco
    dusty disco is offline Fossicker Supporter
    Join Date
    Mar 2007
    Location
    Perth W Australia
    Posts
    60
    Total Downloaded
    0
    Hi Dave

    Thanks for the reply. I was thinking that a taper on the front might jam up with debris etc., so what you say does make sense.

    cheers
    Adrian
    Reply With Quote Reply With Quote
  4. 11th August 2007, 02:27 PM #4
    p38arover's Avatar
    p38arover
    p38arover is offline Major part of the heart and soul of AULRO.com
    Administrator
    I'm here to help you!     Gold Subscriber
    Join Date
    Jan 1970
    Location
    Western Sydney
    Posts
    30,704
    Total Downloaded
    1.63 MB
    The rearward side is the leading edge. Think about it.

    Ron
    Ron B.
    VK2OTC

    2003 L322 Range Rover Vogue 4.4 V8 Auto
    2007 Yamaha XJR1300
    Previous: 1983, 1986 RRC; 1995, 1996 P38A; 1995 Disco1; 1984 V8 County 110; Series IIA



    RIP Bucko - Riding on Forever
    Reply With Quote Reply With Quote
  5. 11th August 2007, 03:06 PM #5
    dusty disco
    dusty disco is offline Fossicker Supporter
    Join Date
    Mar 2007
    Location
    Perth W Australia
    Posts
    60
    Total Downloaded
    0
    Hi Ron

    Yes, the leading edge is towards the rear of the car, and the side I am supposing the square edge goes. The taper would then face the front of the car.

    Thanks for the reply.

    Adrian
    Reply With Quote Reply With Quote
  6. 11th August 2007, 03:16 PM #6
    p38arover's Avatar
    p38arover
    p38arover is offline Major part of the heart and soul of AULRO.com
    Administrator
    I'm here to help you!     Gold Subscriber
    Join Date
    Jan 1970
    Location
    Western Sydney
    Posts
    30,704
    Total Downloaded
    1.63 MB
    The leading edge is chamfered, not the trailing edge

    See http://www.cunningham.me.uk/rangiewi...action_Control

    and http://www.aulro.com/afvb/showthread.php?p=559463 i.e.,
    Quote Originally Posted by Blknight.aus View Post
    5. stand the pad up at 45 degrees on the leading edge and scuff a chamfer on the front
    Ron
    Ron B.
    VK2OTC

    2003 L322 Range Rover Vogue 4.4 V8 Auto
    2007 Yamaha XJR1300
    Previous: 1983, 1986 RRC; 1995, 1996 P38A; 1995 Disco1; 1984 V8 County 110; Series IIA



    RIP Bucko - Riding on Forever
    Reply With Quote Reply With Quote
  7. 11th August 2007, 03:26 PM #7
    Blknight.aus's Avatar
    Blknight.aus
    Blknight.aus is offline RoverLord Vendor
    Join Date
    Aug 2006
    Location
    Melbourn(ish)
    Posts
    26,495
    Total Downloaded
    0
    no, the taper faces the rear. thats the leading edge as the disc moves from rear to front inside the pad (unless for some freaky reason your calipers are on the bottom in which case panic as the rover has rolled off the hoist)
    the trailing edge faces the front of the car.

    The Champfer on the pad goes to the back end of the car.
    Dave

    "In a Landrover the other vehicle is your crumple zone."

    For spelling call Rogets, for mechanicing call me.

    Fozzy, 2.25D SIII Ex DCA Ute
    Tdi autoManual d1 (gave it to the Mupion)
    Archaeoptersix 1990 6x6 dual cab(This things staying)


    If you've benefited from one or more of my posts please remember, your taxes paid for my skill sets, I'm just trying to make sure you get your monies worth.
    If you think you're in front on the deal, pay it forwards.
    Reply With Quote Reply With Quote
  8. 11th August 2007, 03:40 PM #8
    p38arover's Avatar
    p38arover
    p38arover is offline Major part of the heart and soul of AULRO.com
    Administrator
    I'm here to help you!     Gold Subscriber
    Join Date
    Jan 1970
    Location
    Western Sydney
    Posts
    30,704
    Total Downloaded
    1.63 MB
    Quote Originally Posted by Blknight.aus View Post
    no, the taper faces the rear. thats the leading edge as the disc moves from rear to front inside the pad (unless for some freaky reason your calipers are on the bottom in which case panic as the rover has rolled off the hoist)
    the trailing edge faces the front of the car.

    The Champfer on the pad goes to the back end of the car.
    Yep. Agreed. (In a P38A the leading edge is more downward than rearward).

    Ron B.
    VK2OTC

    2003 L322 Range Rover Vogue 4.4 V8 Auto
    2007 Yamaha XJR1300
    Previous: 1983, 1986 RRC; 1995, 1996 P38A; 1995 Disco1; 1984 V8 County 110; Series IIA



    RIP Bucko - Riding on Forever
    Reply With Quote Reply With Quote
  9. 12th August 2007, 09:14 AM #9
    dusty disco
    dusty disco is offline Fossicker Supporter
    Join Date
    Mar 2007
    Location
    Perth W Australia
    Posts
    60
    Total Downloaded
    0
    Well, I seem to have got it wrong. If they squeal then I'll turn 'em around for leading edge taper. Thanks for clarifying this point.

    Adrian
    Reply With Quote Reply With Quote
