  1. 1st January 2016, 09:07 PM #51
    RoverLander
    RoverLander is offline Master Subscriber
    Join Date
    May 2010
    Location
    Southern Sydney
    Posts
    226
    Total Downloaded
    0
    Yes that would probably explain it. I will have to go back and have a look at my emails. It was 4 years ago. It was something to do with the reader autodetecting the protocol but selecting the wrong protocol. Once i manually set it to the correct protocol it was fine. The Reader could only read selected information so it was probably not reading the info on the second canbus system you mention.

    Quote Originally Posted by LandyAndy View Post
    Incase you are unaware,these vehicles run a second canbus system,it doesnt meet international protocols,could explain why your OBDII reader has problems talking to the Land Rover.
    Andrew
    Reply With Quote Reply With Quote
  2. 1st January 2016, 09:20 PM #52
    LandyAndy's Avatar
    LandyAndy
    LandyAndy is offline RoverLord Gold Subscriber
    Join Date
    Feb 2004
    Location
    Williams West Aust
    Posts
    20,998
    Total Downloaded
    0
    Quote Originally Posted by RoverLander View Post
    Yes that would probably explain it. I will have to go back and have a look at my emails. It was 4 years ago. It was something to do with the reader autodetecting the protocol but selecting the wrong protocol. Once i manually set it to the correct protocol it was fine. The Reader could only read selected information so it was probably not reading the info on the second canbus system you mention.
    From what Gordon said on his course,its the entertainment system that runs the second canbus system.
    Andrew
    DISCOVERY IS TO BE DISOWNED
    Midlife Crisis.Im going to get stuck into mine early and ENJOY it.
    Snow White MY14 TDV6 D4
    Alotta Fagina MY14 CAT 12M Motor Grader
    2003 Stacer 525 Sea Master Sport
    I made the 1 millionth AULRO post
    Reply With Quote Reply With Quote
  3. 1st January 2016, 09:22 PM #53
    Bradmc's Avatar
    Bradmc
    Bradmc is offline Fossicker
    Join Date
    Feb 2014
    Location
    Sydney
    Posts
    96
    Total Downloaded
    0
    I don't have a reader. The initial fault codes were from the NRMA service guy. The other faults I mention are what comes up on my dash.
    Reply With Quote Reply With Quote
  4. 3rd January 2016, 05:24 PM #54
    Bradmc's Avatar
    Bradmc
    Bradmc is offline Fossicker
    Join Date
    Feb 2014
    Location
    Sydney
    Posts
    96
    Total Downloaded
    0
    Hi All,

    Just a thought from reading other threads. Could my issues be caused by a faulty wheel speed sensor?

    Anyway, car is off to the dealer tomorrow. LR Care have arranged a tow and, they have also dropped off a Range Rover Evoque today for us to use while the D4 is off the road.

    Props to Land Rover Care.
    Reply With Quote Reply With Quote
  5. 3rd January 2016, 05:35 PM #55
    Graeme
    Graeme is online now Swaggie Vendor
    Join Date
    Jan 1970
    Location
    NSW SW Slopes
    Posts
    12,033
    Total Downloaded
    0
    A faulty wheel speed sensor would cause the ABS faults but not the ecm canbus shut-down faults. The ABS ecu not receiving ecm messages on the can-bus would also cause the ABS messages.
    MY21.5 L405 D350 Vogue SE with 19s. Produce LLAMS for LR/RR, Jeep GC/Dodge Ram
    VK2HFG and APRS W1 digi, RTK base station using LoRa
    Reply With Quote Reply With Quote
  6. 5th January 2016, 04:05 PM #56
    Bradmc's Avatar
    Bradmc
    Bradmc is offline Fossicker
    Join Date
    Feb 2014
    Location
    Sydney
    Posts
    96
    Total Downloaded
    0
    2 days in at LR and no word, it might have them baffled.



    Reply With Quote Reply With Quote
  7. 5th January 2016, 04:42 PM #57
    Stuart02
    Stuart02 is offline Wizard Subscriber
    Join Date
    Feb 2009
    Location
    Melbourne
    Posts
    1,201
    Total Downloaded
    0
    Quote Originally Posted by Bradmc View Post
    2 days in at LR and no word, it might have them baffled.



    Gulp. How's the loaner?
    Now 2016 D4 HSE 'Leo' and Steve the Triumph Speed Twin
    Then 2010 D4 3.0 HSE 'James'
    Then 2010 RRS TDV8 'Roger' w traxide DBS, UHF, Cooper Zeons, Superchips remap
    Then 2010 D4 TDV6 'Jumbo' w traxide DBS
    First love 2002 D2 TD5 'Disco Stu'
    Reply With Quote Reply With Quote
  8. 5th January 2016, 05:28 PM #58
    Bradmc's Avatar
    Bradmc
    Bradmc is offline Fossicker
    Join Date
    Feb 2014
    Location
    Sydney
    Posts
    96
    Total Downloaded
    0
    Quote Originally Posted by Stuart02 View Post
    Gulp. How's the loaner?
    Hehe, my wife said it is much quieter than the D4, but it is still no D4

    She is a good woman.
    Reply With Quote Reply With Quote
  9. 8th January 2016, 01:49 PM #59
    Bradmc's Avatar
    Bradmc
    Bradmc is offline Fossicker
    Join Date
    Feb 2014
    Location
    Sydney
    Posts
    96
    Total Downloaded
    0

    Smile

    Update: Car has been in at LR for 5 days. To be fair, I am not sure they have been working on it for 5 days, as it was towed in and was an unexpected arrival; so it may have been back in the queue of other vehicles booked in.

    The issue they believe is a faulty Steering Angle Sensor (that may have been draining the battery). Part is ordered and i should have the car back on Monday.

    Anyone have issues with that part causing similar issues?

    Anyway, I will update the post when I get the car back and do a bit of my own real world testing; as in driving it.
    Reply With Quote Reply With Quote
  10. 12th January 2016, 06:58 PM #60
    Bradmc's Avatar
    Bradmc
    Bradmc is offline Fossicker
    Join Date
    Feb 2014
    Location
    Sydney
    Posts
    96
    Total Downloaded
    0
    Car is back. 😀

    Multiple fault codes were logged in the system - U0001-88 High Speed CAN-BUS off / SASM (steering angle sensor) fault causing system to throw HDC and ABS faults.

    Steering Angle Sensor replaced.

    Car seems to be fine now. Now to reinstall my DBS.
    Reply With Quote Reply With Quote
