Thread: Defender Spare wheel carrier, Kaymar copy. How to make your own.

OK
Here is the list of parts i used that are Specific to this carrier.....

Pipe work and plates not included... you can find that stuff easy...

The Galvenised Latch
Part number 6506, $23
All States Trailer Spares
www.astss.com.au

Hub and Stub axle
Hub, C0131 (steel not cast) $37
Axle, B0504, $18
Martins Trailer parts
www.trailerparts.net.au

So now you know the source of my bits.

Clarkie

did u get a normal hub and machine it into a sleeve or did you find a steel sleeve from somewere

Originally Posted by mimmo321

did u get a normal hub and machine it into a sleeve or did you find a steel sleeve from somewere

You can buy flangeless hubs from a place in WA.

wa is a bit far from were i am i might just get a sleeve made up or some thing i have bought a straight axle so just a straight forward sleeve will work

if you read the whole post it tells you where i got them.
to get one machined was dearer than the one i got.

$37 from WA post was about $10

Originally Posted by Scallops

I'm keen - been looking at all the aftermarket options - happy to pay you instead. Getting a '07 Fender 110 once available so knock me one up. I guess a PM to sort the details is the way to go.

Dan

PS - Looking again I see you have a Ute - can it be modified to open with the door?

Gday Dan
These are some pic's of my boys series III spare wheel carrier. Solid, opens with door but not sure if it was a standard version, not that it looks like it. I think that it takes a fatty as well as the cheese cutters. Havent tried as yet.

Thanks
Baz

Ps great job Clarkie. Did the landys change the sides for the swing action of the tail gate or is that this 1 not standard??

Originally Posted by Bazz67

Gday Dan
These are some pic's of my boys series III spare wheel carrier. Solid, opens with door but not sure if it was a standard version, not that it looks like it. I think that it takes a fatty as well as the cheese cutters. Havent tried as yet.

Thanks
Baz

Ps great job Clarkie. Did the landys change the sides for the swing action of the tail gate or is that this 1 not standard??

Nah i have a drop down tail gate... Std Series one..

Originally Posted by sclarke

as for the price in the future.... it wont be $350.... thats only for this one i've made.

Clarkie

Have you figured this part out yet.
I'd be definitely interested in one for the '03 Fender.

Cheers
